GRAIN HOPPER SEMI TRAILER (30 M3 – 55 M3)
SPECIFICATIONS
We are ready to consider the issue of manufacturing this equipment, according to the technical specifications of the Customer
SUPERSTRUCTURE
- Damper body is produced from durable steel 09G2S
- There are plastic mallets to prevent wearing and noise on the points that contact with rack
- There are plastic mallets to prevent wearing and noise on the points that contact with rack
AXLE SHAFT
3 - 4 axle shafts with the capacity of 12 tons,
are used
ELEVATING FRONT AXLE SHAFT
Remote operated elevating system for front axle shaft in cabin
ELECTRICAL EQUIPMENT
It is suitable for SAE standards and Tüv regulations Electricity is provided by 7 pin plug from vehicle
There are back lights, brake lights, license plate lamps, trailer reflectors and orange colored warning lights on the sides
There are back lights, brake lights, license plate lamps, trailer reflectors and orange colored warning lights on the sides
KING-PIN
2" DIN 74080 and 3.5" DIN 74083 in steel 42 CRM04. Brand – OMS
HYDRAULIC
Damper movement is provided by level 5 heavy telescopic cylinder which provides 45° tilt angle
PAINT
Rack and superstructure are painted in paint drying oven by Washing + Sanding + 2+1 coat Acrylic Paint
STANDARD ACCESSORIES
Multi-piece plastic fenders that covers back axle shaft tires
1 plate tool box
Control Panel(Mob, air clock, access ramp lever)
Plastic water tank
Spare tire conveyor between trailer legs
Mounting and mounting space
1 plate tool box
Control Panel(Mob, air clock, access ramp lever)
Plastic water tank
Spare tire conveyor between trailer legs
Mounting and mounting space
RACK
Strengthened “I” section centre members are welded automatically by submerged welding machine.
Spar 14 - 16 mm thick made of steel 10HSND or S700
Chassis 5 mm thick made of steel 10HSND or S700, transverse 6 mm thick units made of steel S700
SUSPENSION
- Pneumatic
- spring balancer
- spring balancer
TIRES AND RIMS
385/65 R22,5 tires 6+1
11,75 x 22,5 rims 6+1
11,75 x 22,5 rims 6+1
BRAKE EQUIPMENT
- Wabco ABS
- Wabco EBS
- Wabco EBS
LEGS
Two speed, telescopic, mechanical conveyor legs, with the capacity of 24 tons
FLOOR
-
COLOR
It will be specified according to customer request
OPTIONAL SPECIFICATIONS
European axle shaft group and all kind of equipments
Import and Domestic plates (Domex)
Smart board panel presented with EBS Brake System
Aluminum rims
Axle shaft elevator addition
Company logo is applied according to request
Tire mark according to request
Chassis steel Strenx 700
Import and Domestic plates (Domex)
Smart board panel presented with EBS Brake System
Aluminum rims
Axle shaft elevator addition
Company logo is applied according to request
Tire mark according to request
Chassis steel Strenx 700
